'94-'98 Mustang Halo LED Projector Headlight Installation Instructions

Created by Tyler Rodriquez
Last Updated 5/17/2021

Add a new look to the front of your 1994-98 Ford Mustang with these black Euro-Style projector headlights! These headlights blend seamlessly with the Curves of your Mustang to give you a streamlined new look!

Show More Show Less
Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.

FOLLOW: 94 04 mustang , mustang

Tools Needed:

  • 1/4" Drive Ratchet
  • 10mm Socket
  • Needle Nose Pliers
  • Wire Stripper
  • Wire Crimper
  • 4 Blue Quick Splice Wire Connectors
  • 4 Blue Male Quick Wire Connectors
  • 4 Blue Female Quick Wire Connectors
  • 2 Red Wires (8 Inch)
  • 2 Black Wires (8 Inch)

Installation Instructions:

  1. Locate, and remove the 10mm nut holding in your driver side turn signal housing
    2. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights
  2. Remove the light housing, and remove the bulb from the housing
    3. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights
  3. Locate, and detach the mounting clips holding in your driver side headlight housing
    4. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights
  4. Remove the light housing, and remove the bulb from the housing.
    5. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights
  5. Install the turn signal bulb into the projector headlight
    6. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights
  6. Connect the projector headlights into the headlight harness
    7. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights
  7. Press firmly to snap the headlight into position
    8. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights
  8. Repeat steps 1-7 in order for the opposite side
    9. How To Install SVE Halo LED Projector Headlights - How To Install SVE Halo LED Projector Headlights

Click the link below for wiring installation instructions from Spec-D
Wiring Installation Video
