How To Remove 2010-2014 S197 Mustang Taillights

Created by Jude Horstman / 5 min read
Date Created: 11/10/2022
Last Updated: 11/11/2022

Follow along as we walk you through the steps of removing your 2010-2014 S197 Mustang tail lights!

Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.

FOLLOW: 10 14 mustang , mustang , tail lights , removal

Removing the tail lights on your 2010-2014 Mustang is very straightforward and does not require a lot of tools to get the job done. So follow along, and we'll walk you through the removal steps.

Required Tools:

  • Socket Set
  • Small flat-blade screwdriver
  • Plastic trim removal tool

  1. First, you’ll want to open the trunk by using the key fob or the dedicated switch on the center console. Then, head to the front of the car and disconnect the negative battery cable. It’s always good practice to do this when working with electrical components regardless of the job's complexity. Back at the rear of the car, locate the rearward trim panel.

  2. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  3. Loosen and remove the upper screw-type retainers. There is one on each side. Sometimes these can be difficult to remove, so you may have to gently remove the retainer with a plastic trim removal tool.

  4. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  5. Use the plastic pry tool to remove the two lower push pins. There is one per side as well. These are awkward to access because of the recess in the trim panel.

  6. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  7. Lift straight up on the trim panel to dislodge the clips. Roll it forward and disconnect the trunk light electrical connection.

  8. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  9. Lift up on the spare tire cover and then remove the trim panel from the car.

  10. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  11. Starting on the driver's side, loosen and remove the 13mm bolt securing the trunk carpet to the car. This is optional, but it does allow more room to roll back the carpet to gain access to the tail light nuts.

  12. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  13. Rotate the trunk carpet away from the car's rear. Locate the three nuts securing the tail light. Loosen and remove each nut with an 11mm deep socket.

  14. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  15. Disconnect the electrical connection and push the grommet through the car's body.

  16. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

    How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  17. Shimmy the tail light backward and pass the connector through the opening to remove it from the car.

  18. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  19. Use this opportunity and clean the area. Wipe up any dirt with a microfiber towel and a waterless wash product.

  20. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  21. The steps for the passenger side are the same unless you have a factory-installed subwoofer. Depending on the working area you may have to remove the subwoofer.

  22. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  23. To do this, you’ll need to remove the spare tire cover, remove the retaining hardware, and disconnect the electrical connection.

  24. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

    How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  25. Go ahead and repeat the same steps to remove the passenger side tail light.

  26. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights

  27. If you’re installing new lights or reinstalling the existing ones, simply reverse the removal procedure. After that, you’re good to go!

  28. How To Remove 2010-2014 S197 Mustang Taillights - How To Remove 2010-2014 S197 Mustang Taillights


    We hope this article has helped you remove the tail lights from your 2010-2014 S197 Mustang. That’s all we have for today, so until next time; y’all know what to do for all things S197 Mustang; keep it right here with the real enthusiasts, LMR.com!
