2005-09 Mustang CV2 Chin Spoiler Installation Instructions

Created by Phillip Perez
Last Updated 4/10/2019

Add some serious style to the exterior of your 2005-09 S197 Mustang with the CV2 Chin Spoiler. We will so you just how easy this installation is with this helpful install article!

Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.

FOLLOW: mustang , 05 09 mustang , s197 , installation , tech , exterior , chin spoiler

Chin spoilers are becoming one of the easiest, cheapest and best looking way to add some style to your 2005-09 Mustang. This chin spoiler for your S197 is made of high grade urethane and molded in black so no painting is required!

S197 Mustang Chin Spoiler Installation (SVE 05-09) - mustang chin spoiler install 2005

Our friend Michael stopped by in his black 2009 Mustang GT for our installation. First off, we have to say this is one of the best fitting chin spoilers we have installed on the 05-09 Mustang GT. It uses existing hardware and requires no modification at all.

Tools Needed:

  • Drill
  • Phillips Head Screwdriver
  • 5.5MM Hex Head Bit

Installation Procedure:

Step 1:
To start your installation, you will need to drill out the marked holes on the chin spoiler; they have slight divets in them to show you where to drill for proper installation. As you can see from the picture I sat the chin spoiler in place to ensure that the hole alignment was correct. I also marked the inner fender screw that needs to be removed and circled the extra divet that does not need to be drilled out.
Step 2:
Once you drill out the 2 holes on the inner fender pieces, proceed to drill out the 4 center holes. Once you have drilled your 6 holes out, you will need to remove the philips head screws located on both sides of the inner fender as shown in the picture above. Next you will need to get under the front of the car and remove the 4 hex headed screws from the underside of the bumper cover. These are 5.5MM hex head screws so make sure you have the proper tools for this job.

S197 Mustang Chin Spoiler Installation (SVE 05-09) - mustang chin spoiler installation s197
Step 3:
Once the chin spoiler is lined up, simply reinstall your two inner fender screws and the four hex head screws under the Mustang's bumper and you are done with your CV2 Chin Spoiler installation. Simple as that! This installation will take only about 30 minutes with the right tools and it will completely change the front end of your 2005-09 Mustang GT.
