Find the fuse box diagram for 2010–Present Ford Raptors. Get fuse locations, amperages, and circuit details to quickly troubleshoot electrical issues.
At Late Model Restoration, we know how frustrating it can be to track down a complete and accurate fuse panel diagram for your Ford Raptor. Whether you’re working on a first-gen 2010–2014 Raptor, second-gen 2017–2020, or the latest third-gen 2021–Present models, fuse layouts can vary and cause confusion. That’s why we’ve put together this guide to make things easier for Raptor enthusiasts like yourself. Please note that this information covers 2010–Present Raptors, so there may be slight differences in fuse numbers, amperages, or descriptions depending on the year and trim. Check out the diagrams below and tackle those pesky fuse issues with confidence!
| Number | Amperage | Description |
| 1 | - | PCM Power Relay |
| 2 | - | Starter Relay |
| 3 | - | Blower Motor Relay |
| 4 | - | Rear Window Defrost Relay |
| 5 | - | Cooling Fan High Speed Relay |
| 6 | - | Trailer Tow Relay, Parking Lamp |
| 7 | - | Upfitter Relay 1 |
| 8 | - | Fuel Pump Relay |
| 9 | - | Upfitter Relay 2 |
| 10 | - | Trailer Tow Relay, Battery Charge |
| 11 | 30 | Power Running Board (PRB) Module |
| 12 | 40 | Cooling Fan Low Speed Relay |
| 13 | 30 | Starter Relay |
| 14 | 30 | Seat Control Switch., Passenger Side Front |
| 15 | 40 | Cooling Fan High Speed Relay |
| 16 | - | Not Used |
| 17 | 30 | Trailer Brake Control (TBC) Module |
| 18 | 30 | Upfitter Relay 1 |
| 19 | 30 | Upfitter Relay 2 |
| 20 | 20 | Transfer Case Control Module (TCCM) |
| 21 | 30 | Trailer Tow Battery Charge Relay |
| 22 | 20 | Cigar Lighter, Front |
| 23 | - | A/C Clutch Relay |
| 24 | - | Upfitter Relay 4 |
| 25 | - | Heated Mirror Relay |
| 26 | 10 | PCM Power Relay, Evaporative Emission (EVAP) Canister Vent Solenoid, 6R80 Transmission |
| 27 | 20 | Fuel Pump Relay |
| 28 | 10 | Upfitter Relay 4 |
| 29 | 10 | Integrate Wheel End (IWE) Solenoid |
| 30 | 10 | A/C Clutch Relay |
| 31 | 20 | Trailer Tow Parking Lamp Relay |
| 32 | 40 | Rear Window Defrost Relay |
| 33 | - | Not Used |
| 34 | 40 | PCM Power Relay |
| 35 | - | Not Used |
| 36 | 30 | Anti-Lock Brake System (ABS) Module |
| 37 | ||
| 38 | ||
| 39 | ||
| 40 | Cooling Fan Relay | |
| 41 | 15 | Heated Mirror Relay |
| 42 | - | Not Used |
| 43 | 20 | Reversing Lamp Relay |
| 44 | 15 | Upfitter Relay 3 |
| 45 | 20 | Left and Right Trailer Tow Turn Relays |
| 46 | 15 | Brake Pedal Position (BPP) Switch |
| 47 | 60 | Anti-Lock Brake System (ABS) Module |
| 48 | - | Not Used |
| 49 | 30 | Windshield Wiper Motor |
| 50 | - | Not Used |
| 51 | 40 | Blower Motor Relay |
| 52 | - | Not Used |
| 53 | 5 | Powertrain Control Module (PCM), 6R80 Transmission |
| 54 | 5 | Anti-Lock Brake System (ABS) Module, Transfer Case Control Module (TCCM), Digital Transmission Range (DTR) Sensor, Trailer Tow Battery Charge Relay |
| 55 | 5 | Auto-Dimming Interior Mirror Unit, Rear View Camera Display Mirror |
| 56 | - | Not Used |
| 57 | - | Not Used |
| 58 | 15 | Trailer Tow Connector - Reverse |
| 59 | - | Not Used |
| 60 | Start Diode | |
| 61 | Fuel Pump Motor Diode | |
| 62 | Upfitter Relay 3 | |
| 63 | 25 | Cooling Fan Relay |
| 64 | 30 | Audio Digital Signal Procession (DSP) Module |
| 65 | 20 | Power Point, Instrument Panel |
| 66 | 20 | Power Point, Console 1, w/ Floor Shifter |
| 67 | - | Not Used |
| 68 | 20 | Transfer Case Control Module (TCCM) |
| 69 | 30 | Dual Climate Controlled Seat Module (DCSM), Heated Seat Module |
| 70 | - | Not Used |
| 71 | - | Not Used |
| 72 | 20 | Power Point, Console 1 - w/ Column Shifter Power Point, Console 2 - w/ Floor Shifter |
| 73 | - | Not Used |
| 74 | 30 | Seat Control Switch, Drive Side Front, w/o Memory |
| 75 | 15 | Powertrain Control Module (PCM) |
| 76 | 20 | Brake Pedal Position (BPP) switch, Mass Air Flow / Intake Air Temperature (MAF/IAT) sensor, Variable Camshaft Timing (VCT) solenoids, Heated oxygen sensors (HO2Ss), Evaporative emission (EVAP) canister purge valve, EGR system module, Intake Manifold Runner Control (IMRC) |
| 77 | 10 | Cooling fan relays, A/C clutch relay, Positive Crankshaft Ventilation (PCV) heated fitting, Floor shifter, Overdrive cancel switch |
| 78 | 15 | Coil on Plugs (COPs), Ignition transformer capacitors |
| 79 | 10 | Heated oxygen sensors (HO2Ss), 4R75 transmission |
| 80 | 5 | Steering wheel switches - illumination |
| 81 | - | Not Used |
| 82 | 10 | Trailer Brake Control (TBC) module |
| 83 | ||
| 84 | ||
| 85 | Cooling Fan Low Speed Relay |
Please note that this information covers 2017–2020 F150/Raptors, so there may be slight differences in fuse numbers, amperages, or descriptions depending on the year and trim
| Number | Amperage | Description |
| 1 | - | Not Used |
| 2 | - | Not Used |
| 3 | - | Not Used |
| 4 | - | Not Used |
| 5 | 40 | Rear window defrost grid |
| 6 | - | Not Used |
| 7 | - | Not Used |
| 9 | 30 | Fuel Pump Relay |
| 10 | 40 | Engine cooling fan relay 4 |
| 11 | 60 | Anti-lock Brake System (ABS) module |
| 12 | 50 | Body Control Module (BCM) |
| 13 | 60 | Body Control Module (BCM) |
| 14 | 20 | Audio Digital Signal Processing (DSP) module, Subwoofer amplifier |
| 15 | 25 | Transfer case control module |
| 16 | 10 | Spot Lamp Module (SLM) |
| 17 | 15 | Front Controls Interface Module (FCIM) |
| 18 | 10 | Steering column lock relay |
| 19 | 10 | Multi-contour seat relay |
| 20 | 15 | Rear heated seats/Snow plow relay, Heated seat module (rear) |
| 21 | 15 | Transmission Control Module (TCM), Headlamp right relay |
| 22 | 30 | Windshield wiper |
| 23 | 15 | Rain sensor module |
| 24 | 25 | Engine cooling fan relays, Engine cooling fan motor 2 |
| 25 | - | Not Used |
| 26 | 30 | Driver Seat Module (DSM), Seat control switch (driver side front) |
| 27 | 30 | Seat control switch (passenger side front) |
| 28 | 30 | Front Seat Climate Control Module (SCME) |
| 29 | 40 | Upfitter |
| 31 | - | Not Used |
| 33 | 50 | Engine cooling fan relay 3 |
| 34 | 25 | Trailer tow relay, parking lamp |
| 35 | 20 | Trailer tow module, Trailer tow relays |
| 36 | 25 | Trailer tow module |
| 37 | 50 | Engine cooling fan relay 1 |
| 38 | 10 | Generator |
| 39 | 10 | Integrated Wheel End (IWE) solenoid |
| 40 | 15 | Transfer case control module (TCCM) |
| 41 | 10 | Telescoping mirrors relays |
| 15 | Headlamp left relay | |
| 42 | 30 | Transmission fluid pump |
| 43 | 25 | Horn relay |
| 44 | 10 | A/C clutch relay |
| 45 | 10 | PCM power relay |
| 46 | 10 | Wiper relay |
| 47 | 15 | Upfitter 1 |
| 48 | 15 | Upfitter 2 |
| 49 | 30 | Trailer Brake Control (TBC) module |
| 50 | 30 | Power Running Board (PRB) module |
| 52 | - | Not Used |
| 54 | 30 | DC to DC converter control module, Body Control Module (BCM) (feeds F6, F7, F12, F13, F32, F33) |
| 55 | 40 | Body Control Module (BCM) |
| 56 | 20 | Fuel pump relay |
| 57 | 30 | Electronic park brake module |
| 58 | 30 | Electronic park brake module |
| 59 | 30 | Starter relay |
| 60 | 40 | Blower motor relay |
| 61 | 30 | Anti-lock Brake System (ABS) module |
| 63 | 15 | Exterior mirrors |
| 71 | - | Not Used |
| 72 | 25 | Transfer Case Control Module (TCCM) |
| 73 | - | Not Used |
| 74 | 30 | Power sliding rear window open relay, Power sliding rear window close relay |
| 76 | - | Not Used |
| 84 | - | Not Used |
| 85 | - | Not Used |
| 86 | - | Not Used |
| 87 | 10 | Trailer tow relay, reversing lamps |
| 88 | - | Not Used |
| 89 | 20 | Power point 1, instrument panel |
| 90 | 20 | Power point 2, instrument panel; Power point, console front |
| 91 | 20 | Power point, console rear; Power point, seat |
| 92 | 20 | Power point, console center |
| 93 | 10 | Powertrain Control Module (PCM) |
| 94 | 10 | Upfitter 3 |
| 95 | 25 | EVAP valves, Fuel vapor vent valve, Heated oxygen sensors, Variable camshaft timing solenoids, Intake manifold tuning valves |
| 96 | 10 | Upfitter 4 |
| 97 | 10 | A/C clutch relay, Engine cooling fan relays, Active grille shutters, Turbocharger Bypass Valve (TCBV), Temperature control valve, Transmission fluid warmer, Wastegate control solenoid, Oil pressure control solenoid, Cabin heater coolant pump |
| 98 | 5 | Upfitter 5 |
| 99 | 20 | Ignition coil-on-plugs |
| 100 | 5 | Upfitter 6 |
| 101 | - | Not Used |
| 105 | 10 | Power Steering Control Module (PSCM) |
| 106 | - | Not Used |
| 107 | 10 | Anti-lock Brake System (ABS) module |
| 108 | 10 | Headlamp assembly (left & right) |
| 109 | 10 | Powertrain Control Module (PCM), Transmission Control Module (TCM) |
| 110 | 10 | Transfer case control module, Cruise Control Module (C-CM) |
| 111 | 115 | Transmission fluid pump, 10R80 Transmission |
| 112 | - | Not Used |
| 113 | DC to DC converter control module, Video cameras, Rear lamp assemblies |
| Number | Amperage | Description |
| F1 | 40 | Body Control Module (BCM) |
| F3 | 40 | Body Control Module (BCM) |
| F4 | 30 | Fuel pump control module, Powertrain Control Module (PCM), Fuel injectors |
| F6 | 5 | PCM |
| F7 | 25 | Heated oxygen sensors, EVAP purge valve, VCT solenoids, EVAP canister vent valve, Fuel vapor vent valve (FVVV), EVAP leak detection control module, FTIV, Cylinder deactivation solenoids, Reductant pump control module, EGR cooler bypass valve solenoid |
| F8 | 20 | Front Active Air Dam RH, grille shutter actuators, TCBV, Oil pressure control solenoid, Transmission fluid heater, A/C compressor control, Exhaust heat exchanger valve, Engine cooling fan relays 1/2, Auxiliary fan relay, Crankcase heater, Catalytic heater, Active grille shutter LH |
| F9 | 10 | Ignition coil-on-plugs, ignition transformer capacitor, Glow Plug Control Module (GPCM), Particulate matter sensor 1, NOx sensor modules, Reductant level sensor |
| F10 | 20 | Fuel Rail Pressure Relief Valve (FRPRV), Fuel Volume Control Valve (FVCV) solenoid |
| F11 | 30 | Starter motor |
| F13 | 40 | Blower motor control module |
| F15 | 25 | Horn |
| F19 | 20 | Heated rear seat module, Snowplow package |
| F21 | 10 | Headlamp assembly LH/RH |
| F22 | 10 | Power Steering Control Module (PSCM) |
| F23 | 10 | ABS module |
| F24 | 10 | SOBDMC, PCM, GPCM, TCM |
| F25 | 10 | High mount stoplamp, Generator (secondary), Trailer tow connector, Rear parking aid camera |
| F28 | 50 | ABS module |
| F29 | 50 | ABS module |
| F30 | 40 | Front seat control switch LH, DSM |
| F31 | 30 | Front seat control switch RH |
| F32 | 20 | Media bin power point 1 |
| F33 | 20 | Media bin power point 2 |
| F34 | 20 | Seat power point, Rear console power point |
| F37 | 30 | Rear Gate Trunk Module (RGTM) |
| F38 | 40 | DSM, HVAC control module |
| F40 | 40 | Not used |
| F41 | 25 | Rear sliding window motor |
| F42 | 30 | Trailer Brake Control Module (TBM), Trailer Module (TRM) |
| F47 | 50 | Cooling fan motor 1 |
| F48 | 20 | Heated rear seat module |
| F49 | 50 | Cooling fan motor 2 |
| F50 | 40 | Rear window defrost grid |
| F55 | 30 | Trailer tow connector, Trailer Module (TRM) |
| F56 | 20 | Trailer tow connector, Trailer Module (TRM) |
| F58 | 10 | Trailer tow connector |
| F60 | 15 | Upfitter 1 |
| F61 | 15 | Upfitter 2 |
| F62 | 10 | Upfitter 3 |
| F63 | 10 | Upfitter 4 |
| F64 | 25 | TCCM |
| F65 | 15 | TCM |
| F67 | 20 | Transmission fluid auxiliary pump |
| F69 | 30 | Windshield wiper motor |
| F80 | 15 | Not used |
| F82 | 25 | TCCM |
| F83 | 50 | Electric booster heater |
| F84 | 50 | Electric booster heater |
| F85 | 50 | Electric booster heater |
| F86 | 25 | GPCM |
| F91 | 20 | Trailer Module (TRM) |
| F95 | 15 | SOBDMC |
| F98 | 10 | Engine coolant valve assembly |
| F100 | 15 | Front fog lamp LH, Headlamp assembly LH |
| F101 | 15 | Front fog lamp RH, Headlamp assembly RH |
| F105 | 50 | Steering Angle Sensor Module (SASM) |
| F107 | 30 | Trailer Module (TRM) |
| F116 | 5 | Not used |
| F121 | 30 | Water-in-fuel sensor |
| F124 | 5 | Rain sensor |
| F125 | 10 | USB charge port, USB charge port (rear back panel) |
| F134 | 25 | Driver/Passenger seat cushion modules, Multi-contour seat modules (SCMG/SCMH) |
| F138 | 10 | Tailgate release actuator |
| F139 | 5 | USB charge port (center bin) |
| F146 | 15 | Battery Energy Control Module (BECM) |
| F147 | 40 | CAC cooling fan motor 1 & 2 |
| F159 | 5 | DC/DC converter control module |
| F160 | 10 | Remote Data Link Connector (DLC) |
| F162 | 7.5 | Not used |
| F168 | 5 | Low Voltage Service Disconnect (LVSD |
| F169 | 10 | Electric motor electronics coolant pump |
| F170 | 10 | Pedestrian Alert Control Module (PACM), HV battery coolant pump |
| F202 | 60 | BCM |
| F210 | 30 | BCM |
| F305 | 5 | Upfitter 5 |
| F306 | 5 | Upfitter 6 |
