1986-93 Mustang FatFoxx TFI Module Relocation Kit Installation Instructions

Created by Tyler Rodriquez / 5 min read
Date Created: 5/6/2026
Last Updated: 5/6/2026

Follow these easy steps to install the FatFoxx TDI Module Relocation Kit in your 1986-1993 Mustang.

Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.
If you need to replace your failing TFI module in your 1986-1993 Mustang, this FatFoxx TFI Relocation kit installation instructions will walk you through the easy steps to getting it relocated.

1986-93 Mustang FatFoxx TFI Module Relocation Kit
