2005-09 Mustang Axle Back Exhaust Installation Instructions

Quickly, and easily change up the tone of your S197 with a new set of axel backs!

Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.

FOLLOW: 05 09 mustang , mustang , axle back , exhaust

Tools Required

  • 15mm Socket
  • 13mm Socket

Before You Begin


You will use the factory hangers and hangers hardware. Be sure that they are oriented the correct way once transferred.


Removal Instructions


Step 1:
Use a 15mm socket to loosen the nuts on the clamped connection between the mufflers, and the over-axel pipe

Step 2:
Use a 13mm socket to remove the bolts that secure the muffler hangers to the frame of the vehicle

Step 3:
Remove the 2 hangers on each side of the vehicle to allow removal of the stock mufflers

Step 4:
Slide the muffler off of the over-axle pipe, and set the muffler aside

Installation Steps


Step 1:
Take the hanger mounts off of the stock muffler and put them on to your new mufflers

How To Install Mustang Axle Back Exhaust (05-09) - How To Install Mustang Axle Back Exhaust (05-09)

Step 2:
Place one of the supplied clamps on to the inlet pipe.

How To Install Mustang Axle Back Exhaust (05-09) - How To Install Mustang Axle Back Exhaust (05-09)

Step 4:
Tighten down (Do not completely torque down) the clamp.

How To Install Mustang Axle Back Exhaust (05-09) - How To Install Mustang Axle Back Exhaust (05-09)

Step 3:
Slide the muffler clamp on to the over-axle pipe.

How To Install Mustang Axle Back Exhaust (05-09) - How To Install Mustang Axle Back Exhaust (05-09)

Step 4:
Place the hanger mounts back in to position on the frame and reinstall the factory bolts.

Step 5:
A 13mm open end wrench will be needed to reach the bolts above the muffler.

Step 6:
Level the muffler and tighten the clamp on the muffler inlet enough to hold, but still allow for adjustment. (Repeat the step for the left muffler)

How To Install Mustang Axle Back Exhaust (05-09) - How To Install Mustang Axle Back Exhaust (05-09)

Step 7:
Adjust the position of the muffler to provide a satisfactory fit (a minimum of 1/2" clearance around all parts of the system must be maintained; while keeping travel and vibration in mind.

Step 8:
After adjustments have been made, securely tighten all clamps.

How To Install Mustang Axle Back Exhaust (05-09) - How To Install Mustang Axle Back Exhaust (05-09)

Step 9:
Repeat on the opposite side.

How To Install Mustang Axle Back Exhaust (05-09) - How To Install Mustang Axle Back Exhaust (05-09)


Conclusion


Overall, this removal and install should take roughly 30 minutes to an hour to complete. Be sure to check all of your bolts and make sure they are tight. Now go out and enjoy your new exhaust!
