1992-1996 Bronco Belt Routing Guide

Created by Jay Walling / 3 min read
Date Created: 11/21/2022
Last Updated: 9/17/2026

Before purchasing a replacement serpentine belt for your OBS Bronco, check out this 1992-96 Ford Bronco serpentine belt routing guide.

Show More Show Less
Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.
  • 1992-1996 Bronco Belt Routing Guide
1992-1996 Bronco Belt Routing Guide - 1992-1996 Bronco Belt Routing Guide
Product Links:
Although the information provided is as accurate as possible, some inaccuracies can occur. Please check out the following fitment notes below.

Belt lengths provided in the graphic are intended for factory A/C applications and only apply to 92-96 Ford Broncos with factory pulleys.

Best way to measure for belt length is: How To Measure Serpentine Belt Length
