Use this detailed diagram to identify heater hoses and coolant hose routing on the 4.6L engine in the 1996-2004 Mustang GT. Learn the functions of the heater supply and return hoses, the heater tube assembly, the upper and lower radiator hoses, the thermostat housing, and the water pump to ensure proper cooling system flow and maintenance.
Product LinksHoses & Function- Heater Supply And Return Hose: The heater hose's main function is to transport coolant from the engine to the heater core which is located inside of the vehicle.
- Heater Tube Assembly: Keeps your coolant flowing perfectly and runs under the intake manifold
- Upper Radiator Hose: Connects to the thermostat housing to allow coolant to flow to the radiator for cooling.
- Thermostat/Thermostat Housing: The thermostat housing contains the thermostat, which opens up at a specific temperature to allow coolant to flow through the upper radiator hose, to the radiator
- Water Pump: Connected to the engine and part of the accessory drive. Its purpose is to circulate coolant through the cooling system.
- Lower Radiator Hose: Coolant travels out of the radiator into the lower radiator hose and back into the engine block to extract heat.
We hope this diagram will help with your coolant and heater hose routing needs!
