How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)

Posted 10/29/2019 by Cristian Coronado

Replacing your 3rd brake light with our direct replacement 5.0 resto branded light will be a breeze with our step-by-step install guide!

FOLLOW: fox body , 79 93 mustang , 5.0resto , brakes , installation

How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)

  1. Remove the (2) phillips head screws from either side of the light.

  2. How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)



  3. Carefully bring the light forward and remove both of the light sockets.

  4. How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)



  5. (Optional) If the harness is taped to the harness clip be sure to dislodge it from the light as well.



  6. (Optional) You can take this time to wipe any dirt and grime from the wires and the light sockets.

  7. How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)



  8. (Optional) You can also take this time to properly install the harness clip and tape the wires to the clip with electrical tape.

  9. How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)



  10. (Replace the bulbs if needed) Reinstall the sockets into the lights and position the light into place.

  11. How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)



  12. Install the retaining screws and be careful not to overtighten.

  13. How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)



  14. Check for operation to verify the light is working.

  15. How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93) - How To Install Fox Body Mustang 5.0 Resto Hatchback 3rd Brake Light (87-93)




3rd Brake Light Parts

  • $36.99
    5.0 Resto Logo
  • $6.99
    5.0 Resto Logo

About the Video

1987-1993 Mustang 5.0 Resto Hatchback 3rd Brake Light - Install & Review

Check out our YouTube channel for even more tech tips, installation videos, how-tos, and more. The best place to go for anything Mustang related!

Published on 2018-09-21
Mustang Hatchback 3rd Brake Light.
Whether you need to restore the exterior of your 1987-1993 Mustang GT hatchback, or finish off a 93 Cobra or Saleen rear spoiler installation; this third brake light is the perfect piece! Located in the rear of the vehicle, this 5.0 Resto light acts as a high mount brake lamp, allowing larger vehicles to see your Mustang! Manufactured from the Ford original tooling, this light is a direct replacement, and fits like the factory one. Pick one up today to finish off the restoration on your Fox Body Mustang!

Application: 1987-1993 Mustang Hatchback w/ GT, Cobra, or Saleen Rear Spoiler

Item # LRS-13613B
MPN # E7ZZ-13613
Transcript
What’s up everyone? Landan with lmr.com! Today I’m going to be taking a closer look at this replacement third brake light assembly from 5.0 Resto designed for the 1987 to 1993 hatchback Fox Bodys.

This third brake light is going to appeal to the Fox Mustang owner out there that is wanting to replace a damaged, missing or oxidized factory light… or finish off a ’93 Cobra or Saleen rear spoiler installation.

5.0 Resto’s third brake light is manufactured from Ford tooling so fit and finish is going to be right on the money.

When adding this light to a new spoiler or replacing one… it may be in your best interest to replace the pig tails depending on the their condition.

Something else to consider is new attaching screws… along with the pigtails, these are available on the site.

Fitment wise… this third brake light will fit all 1987 to 1993 Hatchbacks with a GT, Cobra, or Saleen rear spoiler.

To begin the install, remove the two Phillips head screws from either side of the light.

Carefully bring the light forward and then remove both of the light sockets.

If the wiring harness is taped to the harness clip… be sure and dislodge that from the light.

As you can see, our harness was not attached to clip.

Before installing the new light, take this time wipe any dirt and grime from the wires and light sockets.

If you’d like, properly install the harness clip and tape the wires to the clip with quality electrical tape.

Replace the bulbs if needed.

Reinstall the sockets into the light.

Position the light into place.

Install the retaining screws and be careful not to overtighten.

Check for operation and then you’re all finished.

At its relatively low price point, this 5.0 Resto third brake light is a must have for your restoration project or if you’re installing one of the previously mentioned spoilers.
