2024-26 Mustang Ford Performance Supercharger Kit GT/Dark Horse 5.0 by Ford Performance

Price: 9709.95 USD
Availability: InStock

2024-26 Mustang Ford Performance Supercharger Kit GT/Dark Horse 5.0

2024 Mustang Whipple Supercharger | Dyno Numbers & Ride Along (M-6066-M8800)

2024 Supercharged Dark Horse Track Day at Motorsports Park Hastings

Ford Performance's S650 supercharger kit is capable of 810 HP on your Coyote-powered 2024-2026 Mustang 5.0 with a 3yr/36k mile warranty!

Item #M6066M8800
MPN# M-6066-M8800

Everyday Low Price: $9,709.95

Low Stock Only 2 available.

This item is returnable. Details

This item is not eligible for discounts or coupon codes.

Free Shipping over $99

Add to Cart

× close

Images

LMR showroom & will call pickup service will be closed beginning Monday 9/21/26 for renovations until further notice. Need help? Contact Us.

Benefits

Ford Performance Quality
810HP and 615lbft
Developed by Whipple Superchargers
Gen 5 3.0L Twin-Screw Supercharger

Features

Air-To-Water Dual Pass Intercooler
High Flow Intercooler Pump
Ford Performance Calibration
3.875" Pulley

What's in the Box

(1) 3.0L twin-screw supercharger
(1) 92mm GT500 throttle body
(1) Air-to-water dual-pass intercooler
(1) High-flow intercooler pump
(1) 3.875-inch supercharger pulley
(1) High-flow intake system
(8) GT500 fuel injectors
(8) Colder spark plugs
(1) Ford Performance Tomahawk calibration tool
Belt and tensioner components
Wiring harness
Required installation hardware

This part is 50-state legal - CARB E.O. #: D-231-129

Ford Performance S650 Mustang Supercharger Kit - 5.0
Add factory-backed supercharger systems to your 2024-2026 Mustang 5.0 with this Ford Performance supercharger kit! Developed in partnership with Whipple using their 5th generation 3.0 liter supercharger features an all-new rotor profile, inverted front feed rotor housing, and dual-core dual-pass intercooler system that can unleash up to 810hp and 615 lb.-ft. of torque on your S650 Coyote engine! Whipple's unique twin screw supercharger, 3.875" pulley, massive air-to-water intercooler, oversized front feed air system, and Ford Performance exclusive calibration keeps the power-train safe and secure at these power levels. No internal modifications or grinding of the engine block are required for installation. Ford Performance's supercharger kit comes complete with all the necessary parts and hardware for installation. Engineered and tested to Ford Motor Company's rigorous standards and comes with a limited 3-year or 36,000-mile Powertrain Warranty when registered and installed by a Ford Dealer!

Ford Performance Quality
The system makes that much power on only 91-octane fuel, giving you more power per lb of boost than any other system. Utilizing a superior front feed inlet style for a very simple, less restrictive, and more room for the air-to-water intercooler. Featuring a state-of-the-art air intake system that includes a massive Y intake setup, allowing for unparalleled free flow of air into the supercharger. Self-contained oversized oil system for dramatically reduced oil temps in even the most demanding conditions. Also included is a single 92mm GT500 throttle body, colder spark plugs, and GT500 port fuel injectors. A proven 6-rib belt system with a heavy-duty spring-loaded tensioner and adjustable idler system. Plug-and-play wiring harness and flash tool help speed up installation and programming. Ford Performances PCM calibration using their Tomahawk flash tool reconfigures all the necessary engine functions, including fuel, spark, knock detection, torque management, transmission control, and electronic throttle control.

Does this Ford Performance Supercharger Kit fit my 2024-2026 Mustang?

Compatible applications:

2024 Ford Mustang GT 5.0
2024 Ford Mustang Dark Horse
2025 Ford Mustang GT 5.0
2025 Ford Mustang Dark Horse
2026 Ford Mustang GT 5.0
2026 Ford Mustang Dark Horse

How Much Power Does the Ford Performance Supercharger Make?

The Ford Performance S650 Mustang supercharger kit is designed to deliver up to 810 horsepower and 615 lb.-ft. of torque on applicable 2024-2026 Mustang 5.0L Coyote models. The system is rated at 810 HP at 7,500 RPM and 615 lb.-ft. of torque at 4,800 RPM for active-exhaust-equipped Mustangs, with a 10 HP reduction for models without active exhaust. The power comes from the Gen 5 3.0L twin-screw supercharger, high-flow intake system, 92mm GT500 throttle body, air-to-water intercooling system, and Ford Performance calibration.

The 810 HP figure is an advertised engine horsepower rating, not wheel horsepower. Actual dyno results will vary based on drivetrain losses, fuel, temperature, dyno type, and vehicle configuration. Ford Performance specifies premium 91+ octane fuel for the system, and the kit is designed specifically for the S650 Mustang 5.0L platform without requiring internal engine modifications or grinding of the engine block.

This product is intended for off-road use only. Off-Road Disclaimer

Ford Performance Racing Parts "Packs" and Component Parts Limited Warranty - Click Here
Ford Performance Racing Parts - NO WARRANTY - Click Here
Ford Performance Racing Parts Crate Engine Limited Warranty - Click Here

Ford Mustang - 2024, 2025, 2026
Sub Models: GT, Dark Horse
Engines: 5.0

Fitment Notice

Fits 2024-2026 Mustang 5.0 & Dark Horse Models
The Ford Performance package delivers 810 HP @ 7,500 RPM and 615 lb.-ft. of torque @ 4,800 RPM for active exhaust-equipped Mustangs. (10 HP less for non-active exhaust). ***PREMIUM FUEL REQUIRED*** [91+ octane]
CARB EO#: D-231-129 Certified for 2024-25 model year only 2026 year models are Not carb legal.

Warranty information

Ford Performance EXCLUSIVE 3yr/36k mile warranty when installed by a Ford dealer or ASE-certified technician and registered through the Ford Performance Parts Tech-line. For registration assistance, please call (800) 367-3788.
