1982-93 Fox Body Mustang SVE Coyote Swap A/C Kits | Product Highlight

Created by Taylor Ward
Last Updated 5/17/2021

Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.

FOLLOW: fox body , 79 93 mustang , sve , mustang coyote swap

Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93

SVE COYOTE SWAP A/C KITS

Often times, during your coyote swap, getting your air conditioning to cool properly can be one of the most common issues, that’s why we came out with our two kits. Our SVE exclusive coyote swap A/C kits feature all brand-new components designed for 1982-93 Mustangs that utilize the KRC Power Steering Pump Kit or the Speed Drive Kit From Power By The Hour. The highlight of the KRC hit is having the A/C compressor mounted in the factory coyote location, while the PBH speed drive kit has the benefit of the adapter bracket slightly moving the location of the 6 rib compressor back into the factory coyote location.

Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93

SVE QUALITY COMPONENTS

SVE products are designed and manufactured keeping OEM fit and finish in mind to provide simple, yet effective air conditioning solutions for coyote swap Fox Body projects. These components consist of:

  • New Compressor & Clutch w/ 8 Or 6 Rib Pulley Depending On Kit
  • A/C Compressor Suction/Discharge Manifold
  • A/C Compressor To Engine Block Bolts For KRC Kit ONLY
  • A/C Compressor Clutch Pigtail
  • A/C Accumulator & Hose Assembly
  • A/C Cycling Switch
  • A/C Clutch Cycling Switch Harness
  • A/C Stretch Belt For KRC Kit ONLY
  • Condenser
  • Evaporator Core
  • A/C Liquid Line From Evaporator To Condenser
  • Orifice Tube
  • Machined Spacers For KRC Kit ONLY
  • Manifold Fitting Retaining Bolt
  • Replacement O-Rings

The result of all of these components is a bolt-on A/C kit that provides a superb fit and finish, while in turn simplifies the process of adding air conditioning to a coyote swapped Fox Body Mustang.

SVE Limited Warranty



FITMENT & INSTALLATION NOTES


Install Video | Install Article


KRC KIT IMAGES

Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93


PBH KIT IMAGES

Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93 - Product Highlight - Fox Body Mustang SVE Coyote Swap A/C Kit | 82-93


Fitment Notes

  • This kit will directly fit 1987-93 Fox Body Mustangs, but for 1982-86 owners, you will have to drop the HVAC box, open it up and retrofit the evaporator in this kit.
  • The kit will only fit factory Ford A/C equipped 1982-93 Mustang and will not fit Mustangs that had dealer-installed A/C systems when new.
  • Designed for Mustang using the KRC Power Steering Pump Kit or Mustangs utilizing the Power By The Hour Speed Drive Kit.
  • The aluminum tubing may have to be clocked in order to clear specific components and to ensure an acceptable fit and finish.
  • The front sway bar brackets will need to be removed due to the orientation of the manifold fitting. It is highly recommended that these be removed before any paintwork. This can be done by carefully drilling out the spot welds, welding them up, and then painting the engine bay. Another way is that you can cut these flush and touch up the area with touch up paint.
  • Custom fabrication is needed in order to run a front sway bar.

Installation Notes

  • Doesn’t come with PAG oil, R134a refrigerant, or A/C condenser mounting brackets.
  • The 8 machined spacers will need to be placed between the engine block and A/C compressor to space out the compressor for proper belt alignment and tension.
  • The 6 rib A/C stretch belt will need to be installed onto the first 6 ribs of the compressor pulley.


APPLICATION

  • Fits 1982-1993 Mustang w/ KRC Power Steering Pump Kit or Mustangs utilizing the Power By The Hour Speed Drive Kit.
  • Fits 1982-1986 Mustang when utilizing the included evaporator.
  • Fits 1987-1993 Mustang.

Fox Body Coyote Swap A/C Kits


About the Video

SVE Fox Body Mustang Coyote Swap A/C Kit - Review (82-93)

Check out our YouTube channel for even more tech tips, installation videos, how-tos, and more. The best place to go for anything Mustang related!

Published on 2019-12-17
Ensure your coyote swapped 1982-1993 Fox Body Mustang is complete with the comfort of ice-cold air conditioning with SVE's exclusive coyote swap a/c kit! After thorough research and development, SVE has created a problem-solving, solution-based product by putting together an air conditioning kit for the ever so popular coyote engine swap. Featuring all brand new components, this is a complete a/c kit! SVE designed this kit for 1982-1993 Mustangs utilizing the KRC Power Steering Pump Kit OR a manual steering rack conversion. The main benefit of this kit is that the a/c compressor is mounted in the factory coyote location. SVE includes machined spacers to properly mount and space the 8 rib compressor away from the engine block to achieve sufficient belt tension and belt alignment.

Application
Fits 1987-1993 Mustang
Fits 1982-1993 Mustang w/ KRC Power Steering Pump Kit or Manual Steering Rack Conversion
Fits 1982-1986 Mustang when utilizing the included evaporator

Buy Coyote Swap A/C Kit: https://latemodelres.to/19703-COY
Buy Coyote Swap A/C Kit - PBH Speed Drive: https://latemodelres.to/19703-PBH
Buy A/C Condenser Mounting Bracket: https://latemodelres.to/19712BRKT-K
Buy 5.0 Resto Front Sway Bar Brackets: https://latemodelres.to/5486A_YouTube

How To Install SVE Coyote Swap Fox Body Mustang A/C Kit (82-93): https://youtu.be/0DVFk3uUsOg

Intro & Backstory | 0:00
A/C Kit Details | 0:36
Power By The Hour Kit | 1:20
KRC Generic Kit | 1:36
Fitment & Install Details | 2:24
Front Sway Bar & Brackets Info | 3:00
A/C Clocking | 3:34
Final Thoughts | 3:52
