How To Install SVE Mustang Coyote Swap Hydroboost Kit | 1979-04

Last Updated 10/9/2020 by Taylor Ward

Learn how to install LMR's SVE Coyote Swapped Hydroboost Kit on your 1979-2004 Mustang! Our step-by-step article and video has all the info you should need!

Viewing this install and using the information shared is subject to the terms set forth here - View the LMR Install Instructions Disclaimer.

FOLLOW: mustang coyote swap , 79 93 mustang , 94 04 mustang

How To Install SVE Mustang Coyote Swap Hydroboost Kit | 1979-04 - How To Install SVE Mustang Coyote Swap Hydroboost Kit | 1979-04

This video will go over the proper routing and placement of all of the hoses and their associated components and before you get started with the install, we recommend neatly laying out all of the components which will give you the opportunity to familiarize yourself with everything. We highly recommend using a fender mat and leave everything loose until all of the hoses are installed. This will help with the final clocking and positioning of the hoses.

As with any swap or retro-fit, there are a number of variables involved. Due to this, SVE can not guarantee that this plumbing kit will work for everyone's application.


Jump To: KRC | PBH

KRC Coyote Swap Hydroboost Plumbing Kit

Ensure the hydroboost system on your 1979-2004 Coyote swapped Mustang is properly plumbed with SVE's premium hydroboost plumbing kit! When it comes to Coyote swapped Mustangs, there are multiple ways to approach this swap. Regardless of the route, there is a desire for the luxury of hydroboost assisted brakes and power steering. After performing several coyote swaps of their own, SVE thoroughly researched and developed a viable solution based kit to properly plumb the hydroboost system. SVE specifically designed this kit for cars utilizing the KRC Power Steering Pump Kit and a hydroboost assembly from a 1999-2004 V8 Mustang.


KRC Hydroboost Pump Premium Components

SVE utilizes premium components within this plumbing kit to provide power assist brakes and power steering for coyote swapped 1979-2004 Mustangs with the KRC Power Steering Pump Kit. SVE includes (2) -6 AN black nylon braided high-pressure hoses that have specific lengths and are pre-terminated with black -6 AN fittings for an easy, direct install. Along with the high-pressure hoses, (2) 90 degree banjo fittings and bolts for the hydro-boost, a small fitting that converts the return port on the hydro-boost assembly to AN, a Y-block with -6 AN fittings, (4) pre-terminated -6 AN nylon braided return hoses, steering rack fittings, (3) adel clamps and (2) nuts for hose management, a bag of zip-ties, and thread locking compound for hydraulic applications. In this kit, the two of the return hoses use tube seal clamps to secure the nylon braided hose to the factory cooler tube. The tube-seal clamps provide the look of a traditional AN fitting, but features a worm gear clamp for ease of use. By utilizing these high-performance components, SVE was able to successfully provide a bolt-on plumbing kit with an exceptional fit and finish! SVE is proud to offer this kit to eliminate all of the guesswork for your coyote swap project to help you save time and money!


What's In The Box?

  • (1) High-Pressure Supply Hose: KRC Pump to Hydroboost
  • (1) High-Pressure Supply Hose: Steering Rack to Hydroboost
  • (1) Power Steering Return Hose: Steering Rack to Steering Cooler Tube
  • (1) Power Steering Return Hose: "Y" Fitting to KRC Pump Return fitting
  • (1) Power Steering Return Hose: Steering Cooler Tube to "Y" Fitting
  • (1) Power Steering Return Hose: Hydroboost Return Port to "Y" Fitting
  • (2) -6AN 90 Degree Banjo Fittings & Bolts
  • (1) -6AN Black Y Block Fitting
  • (1) Hydroboost AN Conversion Fitting
  • (2) -6AN Power Steering Rack Fittings
  • (3) 5/8" Insulated Adel Hose Clamps
  • (2) Retaining Nuts
  • (1) Bag of Zip Ties
  • (4) Copper Washers
  • (2) Tubes Threadlock Compound


PBH Coyote Swap Hydroboost Plumbing Kit

Ensure the hydroboost system on your 1979-2004 Coyote Swapped Mustang is properly plumbed with SVE's premium hydroboost plumbing kit! When it comes to coyote swapped 1979-2004 Mustangs, there are multiple ways to approach this swap. Regardless of the route, there is a desire for the luxury of hydroboost assisted brakes and power steering. After performing several coyote swaps of their own, SVE researched and developed a viable solution based kit to properly plumb the hydroboost system. SVE specifically designed this kit for cars utilizing the Power By The Hour Speed Drive setup and a hydroboost assembly from a 1999-2004 V8 Mustang.


PBH Hydroboost Pump Premium Components

SVE utilizes premium components within this plumbing kit to provide power assist brakes and power steering for coyote swapped 1979-2004 Mustangs with the Power By The Hour Speed Drive setup. SVE includes (2) black nylon braided high-pressure hoses that have the correct length and are pre-terminated with black -6 AN fittings for an easy, direct install. Along with the high-pressure hoses, SVE provides their proprietary power steering pump fitting, a Teflon seal for this fitting, (2) 90 degree banjo fittings and bolts for the hydro-boost, a rubber return hose with a molded 90-degree end, a Tee fitting, (10) clamps, (2) two-foot rubber return hoses that will be cut-to-fit, (1) large rubber return hose that is also cut-to-fit, steering rack fittings, a factory-style return hose that connects to the steering rack and factory power steering cooler tube, and thread locking compound for hydraulic applications. The main benefit of this kit is that the return lines are constructed of a universal, power steering grade material, allowing each line to be custom routed and tailored to the end user's desired specifications. By utilizing these high-quality components, SVE was able to successfully provide a bolt-on plumbing kit with an exceptional fit and finish! SVE is proud to offer this kit to eliminate all of the guesswork for your coyote swap project to help you save time and money!


What's In The Box?

  • (1) High-Pressure Supply Hose: OEM Pump to Hydroboost
  • (1) High-Pressure Supply Hose: Steering Rack to Hydroboost
  • (1) Low-Pressure Return Hose: Steering Rack to Steering Cooler Tube
  • (1) Low Pressure Return Hose: OEM Pump to Reservoir
  • (1) Low-Pressure Return Hose: Steering Cooler Tube to Tee Fitting
  • (1) Low-Pressure Return Hose: Tee Fitting to Reservoir
  • (1) Low-Pressure Return Hose: Hydroboost to Tee Fitting
  • (2) -6AN 90 Degree Banjo Fittings & Bolts
  • (1) -6AN Power Steering Pump Fitting
  • (2) Power Steering Rack to -6AN Line Conversion Fittings
  • (1) Brass Tee Fitting
  • (2) Power Steering Hose Fittings Seals
  • (10) Hose Clamps
  • (4) Copper Washers
  • (2) Tubes Threadlock Compound
  • (1) Bag of Zip Ties
