Fox Body Suspension Guide

Posted 2/20/2014 by Jeff Jimenez

Check out our installation videos and tech articles here! We cover everything from lowering spring to rear control arm installation.

FOLLOW: mustang , 79 93 mustang , fox body , tech guide , 5.0resto , sve , suspension

Get your Fox Body Mustang’s suspension handling better with the help of our Suspension Guide! We will cover topics such as lowering spring installation to rear lower control arm installation. Best of all we will even show you on video how to install these components on your Stang. You will find more tech articles and installation video below.

Be sure to shop our complete line of suspension components below:

Fox Body Suspension Parts

Fox Body Mustang Restoration Suspension Guide - fox body mustang restoration suspension

79-93 Mustang Suspension News & Products

Mustang Lowering Spring Installation (79-04)

Tired of hearing “needs a drop” every time you post a picture of your Stang? SVE lowering springs can solve this problem! These Mustang lowering springs are made in America for guaranteed quality and performance! They are designed to fit 79-04 Fox Body, SN-95 & New Edge V8 Mustangs. These lowering springs will drastica... more

Fox Body Disc Brake Conversion Guide: SVE 5 Lug Kit

Follow along in this step-by-step installation article to see how you can transform your Fox Body with a weekend worth of work! LatemodelResto employee Lee has been on a mission to build the ultimate daily driven road race Fox Body Mustang. Lee started with Eibach Pro Kit lowering springs, UPR control arms and T... more

Mustang Bump Steer Correction Explained

When altering the suspension of your Mustang, bump steer is an issue that many enthusiasts run into. The geometrical inconsistency due to bump steer can cause your Mustang to handle in an incorrect manner. Definition of bump steer: Bump-steer is a change in toe angle caused by the suspension moving up or down. Bump-... more


About the Video

Mustang Lowering Springs Install - SVE Springs & Caster Camber Plates (79-04)

Check out our YouTube channel for even more tech tips, installation videos, how-tos, and more. The best place to go for anything Mustang related!

Published on 2013-08-07
Adding a set of lowering springs to any Mustang is a must! Not only do you get the benefits of better handling but you also get rid of that 4x4 stance that comes on all factory Mustangs. Not all lowering springs are created the same and that was the case with Tyler's Competition Orange GT. Cheap lowering springs had him avoiding every pot-hole and speed bump he saw in fears of bottoming out. Installing a set of lowering springs on your Stang can be done in your garage and will take first time spring installers less than a couple hours to complete.

Add an awesome stance to your Fox Body, SN95 or New Edge Mustang with a set of SVE Lowering Springs. We also carry lowering springs from Eibach, Steeda, Ford Racing & BBK. Don't forget to pick up urethane spring isolators and caster camber plates to finish off your spring install.

Brand: SVE
Part #: SVE-5300A
Fits: Ford Mustang (with V8) GT, SVT Cobra (93-98), Mach 1, Bullitt
Years: 1979 (79) - 1980 (80) - 1981 (81) - 1982 (82) - 1983 (83) - 1984 (84) - 1985 (85) - 1986 (86) - 1987 (87) - 1988 (88) - 1989 (89) - 1990 (90) - 1991 (91) - 1992 (92) - 1993 (93) - 1994 (94) - 1995 (95) - 1996 (96) - 1997 (97) - 1998 (98) - 1999 (99) - 2000 (00) - 2001 (01) - 2002 (02) - 2003 (03) - 2004 (04)

79-93 5.0L Mustang Coupe and Hatchback (including Cobra) - 1.2" front/1.0" rear drop
94-04 4.6/5.0L Mustang hardtop - 1.5" front/1.5" rear drop
94-98 Cobra hardtop - 1.5" front/1.5" rear drop
03-04 Mach 1 hardtop - 1.1" front/1.0" rear drop
2001 Bullitt hardtop - 1.1" front/1.0" rear drop
JONATHAN MCDONALD: If you've picked up a used Mustang, more than likely it's already got a few modifications done to it. Such is the case with our '04 GT here. The previous owner installed a set of springs that did a great job of lowering the car, but it rides like crap, handling is poor, and it bottoms out if you even look at a bump. And they didn't install any caster camber plates, so the alignment's off and it's wearing the front tires.

We're going to address all of these issues with our SVE Springing Caster Camber Plate Kit. It includes a set of our '79 to '04 V8 hard-top springs, caster camber plates for either '79 to '89, '90 to '93, or '94 to '04, and a set of urethane spring isolators. This is going to greatly improve the ride quality and handling, and we'll be able to get that alignment back in spec so we're not going to be wearing out those expensive tires anymore.

You'll start by supporting your car on jack stands on all four corners and remove all four wheels.

Well, the inside of this tire was completely worn flat, it was splitting, and it's about to blow out. And this is what you want to avoid by putting caster camber plates on when you install your lowering springs. That way you can get your alignment back correct.

Remove your front sway bar end links and rotate your sway bar up out of the way. Remove your two caliper retaining bolts on one side. Slide the caliper off the rotor and remove the rotor from the hub.

Take off your ABS retaining nut, remove the retaining bolt, and slide the sensor out of the spindle. Support the lower control arm with a jack, and you can remove your strut nuts and bolts and free the spindle from the strut. Lower the jack to allow the control arm to hang, and you can remove your front spring.

Grab one of your new front springs, slide your urethane isolators leaders into place, pop your spring into the saddle, and jack up on the control arm. Remove your upper strut nut. Remove the strut from the car. With a drill, remove the rivet from the stock camber plate. And then remove the stock camber plate hardware and pull the plate off the car.

On the new SVE caster camber plates, the notch on the bolt plate goes forward. Slide the bolt plate from underneath the strut tower. Then you can slide the bearing plate on top of the strut tower. Position your slots as per the installation instructions. Install your retaining nuts.

This is a good opportunity to replace your struts if they're bad like these. If you're replacing struts, be sure to slide your rubber bumper from your old strut onto your new strut, and also transfer your dust cover. Trim the rubber on your dust cover according to the instructions if it's needed.

Install the spacer stack as per the installation instructions. Slide your strut shaft into the caster camber plate bearing and tighten the nut. Slide your spindle into the strut. Reinstall and tighten the strut hardware. Go ahead and reassemble your brakes and ABS sensor and reattach your front sway bar.

Installation of the rear springs typically only requires you to remove the lower shock bolts and allow the rear end to fully droop so you can pop out your rear springs. We took the opportunity to go ahead and install some of our SVE rear control arms. With your old springs out of the way, go ahead and pop your rear urethane isolators into place. Slide your new spring up into the spring pocket, making sure that the pigtail at the bottom of the spring is facing rearward with the face of the cut lined up in the center of the control arm. Go ahead and button up the rear, put your wheels and tires back on, and lower the car.

With just a few parts and an afternoon worth of your time, you can greatly transform the handling characteristics and ride quality of your Mustang. Keep in mind that you never know what has happened to your car before you've got a hold of it, so be prepared for anything. Also when installing one of our SVE suspension kits, it's a great time to check out our extensive suspension section at and pick up a new set of shocks and struts for your car.
